M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors

M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors

  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
  • M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors
Product Details:
Place of Origin: China Mainland
Brand Name: Jetacon
Certification: CE
Model Number: M12 Connectors
Payment & Shipping Terms:
Minimum Order Quantity: 5 pieces
Price: US $2.99 / Piece
Packaging Details: Standard Export Carton
Delivery Time: 3-5 days
Payment Terms: T/T, L/C, Paypal, Payoneer
Supply Ability: 1000 /Pieces per Day
Contact Now
Detailed Product Description
Material: Stainless Steel Waterproof: IP65

Specification:

Number of connectors: 4 / 5 / 8 Pin

Wire gauge in m㎡: Max*0.75mm2;

Protection level: IP67

Temination: Screw

Cable range: Φ4--Φ7mm / Φ7--Φ9mm

Temperature rating: -25°C~85°C

Material group: 30 / 60 / 250v

Pin contact: CuZn

Contact Plating: Au

Male insert: PA

Contact resistance: Less than 3.0mΩ

Mechanical operat: More than 100 Steckzyklen

Overvoltage categorie: 2

Housing cante connect:PA

Rated current(40°): 2A/ 4A

Rated imoulse voltage: 800/ 1500/ 2500V

M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors 0

M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors 1

M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors 2

M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors 3

M12 Sensor Connector Waterproof Male Female Plug Screw Coupling 3 4 5 8 12 Pin A type Sensor Connectors 4
