5.00mm Pitch PCB Mounted Screw Terminal Blocks Right Angle 2P to 20P Blue

5.00mm Pitch PCB Mounted Screw Terminal Blocks Right Angle 2P to 20P Blue

    • 5.00mm Pitch PCB Mounted Screw Terminal Blocks Right Angle 2P to 20P Blue
    • 5.00mm Pitch PCB Mounted Screw Terminal Blocks Right Angle 2P to 20P Blue
    • 5.00mm Pitch PCB Mounted Screw Terminal Blocks Right Angle 2P to 20P Blue
  • 5.00mm Pitch PCB Mounted Screw Terminal Blocks Right Angle 2P to 20P Blue

    Product Details:

    Place of Origin: Guang Dong
    Brand Name: Jetacon
    Certification: UL, CE
    Model Number: EG300R-5.00

    Payment & Shipping Terms:

    Minimum Order Quantity: 500
    Price: Get latest price
    Packaging Details: Standard Export Carton
    Delivery Time: 7-20 working days
    Payment Terms: T/T, L/C, Paypal, Payoneer
    Supply Ability: 1KK poles monthly
    Contact Now
    Detailed Product Description
    Number Of Contacts: 11 - 20 Conductor Size: 11 - 20 AWG
    Type: PCB

    Specifications:

    Condition: Brand New
    Certification: CE, Rohs
    Pitch: 5.00mm
    Poles: 2 Pins to 20 pins
    Color:Blue
    Torque: 0.2Nm
    Strip length: 5-6mm
    Rated voltage: 300V
    Rated current:10A
    Insulation resistance: 5000MΩ/1000V
    Contact resistance: 20mΩ
    Withstanding voltage: 2000V/1min
    Wire range: 28~16AWG


    Note:

    The terminal blocks are in stock  from 2 poles to 20 poles
