| Place of Origin: | Guang Dong |
| Brand Name: | Jetacon |
| Certification: | UL, CE |
| Model Number: | YJS-351TR |
| Minimum Order Quantity: | 10 Pairs |
|---|---|
| Price: | US $14.99 / Pair |
| Packaging Details: | Standard Export Carton |
| Delivery Time: | 7-20 working days |
| Payment Terms: | T/T, L/C, Paypal, Payoneer |
| Supply Ability: | 1KK poles monthly |
| Connnector A: | BNC | Connector B: | Terminal Blocks |
|---|---|---|---|
| Weight: | 40g |
1 Channel Active Balun Long Distance High Density
1.0 Balun + Cat5 cable = Coaxial cable + BNC
2.0 Active balun
3.0 1 Channel
Descriptions:
Compatible with all HD-AHD, HD-TVI, HD-CVI
Up to 450m for 720P CVI Camera
Up to 300m for 1080P CVI Camera
Up to 500m for 720P/1080P TVI Camera
Up to 800m for 720P AHD Camera
Up to 600m for 1080p AHD Camera
Power 12VDC
BNC:75ΩUTP(Screwless)Terminal Blocks or UTP RJ45
Wire type One Unshielded Twisted
Resistance 52 ohms per 1,000 ft(18 ohms per 100m)
Support NTSC, PAL and SECAM video format
Full motion CCTV video at long distance(Max .9,000ft/3000M)
Built-in linearty, Sharpness and Chroma control
Enable unparalleled common interferences rejection
Built-in transient Protection
2 pcs ( one pair ) * Video Balun Transceivers
